KIP 880 Multi-Touch Production Color Print System
Don't Pay $89,000.00
$83,000.00
SAVE $6,000.00
Australia Wide
Delivery
Key Specs
Up to 268m²/ hr
Scan
Scan Speed Colour: Scan resolution: up to 600 dpi
Copy
Ink Variety
Application
Connectivity
Paper Size
- Description
- Specifications
- Related Products
- Delivery
- Reviews (1)
Description
Ultimate wide format functionality!
The KIP 880 delivers unmatched multi-function copy, scan and print performance for high demand enterprise workflow. Engineered to deliver vibrant consistent color quality from first to final print. The integrated dual footprint configuration multitasks scan and print production, saving valuable project time. Smart touchscreen automation simplifies complex copy, scan and print processes for single touch control.
Features
-
- •4 Roll Multi-Function System with Integrated Scanner
-
- •KIP 880 includes a KIP 720 CIS Scanner
-
- •12” Smart System K Touchscreen
-
- •Standard Front Stacking
-
- •Optional Rear Stacking or KIPFold
-
- •KIP System K Print Management Suite
-
- •Windows and AutoCAD Drivers
-
- •Workflow Automation
Specifications
General | |
---|---|
2/4 Roll Colour and Black & White Printer | Colour and black & white printer with intelligent KIP System K touchscreen |
2/4 Roll Colour and Black & White Print/Copy/Scan | Colour and black & white printer with intelligent Print/Copy/Scan KIP System K touchscreen for Print/Copy and Scan functions |
System Scanners | KIP 880: KIP 720 CIS Scanner |
Scanner Stand | KIP 720 / KIP 2300 Scanner Stand (for the KIP 880 – 890 or optional for stand-alone scan applications) |
Stacking Systems (standard) | Front Stacking Print Tray |
Description | High production colour and black & white wide format print/copy/scan |
Type | LED Array Electro photography with organic photoconductor (OPC drum) Contact Development using non magnetic mono-component toner |
Configurations | Printer or multi-function system (print/copy/scan) |
Speed | Up to 268 sqm per hour in either black & white or colour regardless of image type or print resolution |
Warm Up Time | Instant from standby, less than 6 minutes from power on |
Toner | Four colour (CMYK), dry toner, print images are UV resistant and waterproof |
Input Power | EU/UK: 220 – 240 V, 50/60 Hz, 20 A |
Power Consumption | Ready: 0.6 kWh. Printing: 1.9 kWh, Warm Up: 3.4 kWh, Sleep Mode: 3 Wh |
Acoustic Noise | < 65 db Printing |
Ozone | < 0.05 ppm (average of 8 hours) |
Dimensions (W x D x H) | KIP 880 – 890: 1970 x 1080 x 1220 mm |
Weight | KIP 880: 556 kg Weight of the KIP 880 – 890 is dependent on the scanner model – KIP 720 noted |
Printer | |
Print resolution | 600 x 2,400 dpi |
Paper capacity | 280 sqm ( 2 rolls + cut sheet ) 560 sqm ( 4 rolls + cut sheet ) |
Output sizes width (roll media) | 297 mm – 914 mm |
Output sizes length (roll media) | 210 mm minimum, 64 m maximum (actual length may be dependent on media type and file type limitations) |
Paper weight (roll media) | Bond: 67 – 150 gsm, Film: 3 – 4 mil Double Matte Polyester, Tracing: 67 – 75 gsm Banner and Gloss: see KIP 800 Media Guide |
Sheet Bypass | Up to 150 gsm bond / Maximum sheet size 914 mm x manageable length / Minimum sheet size A3 |
Media types | Bond Paper: Economical Bond, Standard Bond. Specialty Bond paper: Presentation Bond, Heavy Weight Bond. Polyester Film: 3 mil Clear, 3 mil Double Matte, 4 mil White Opaque. Banner Media: Fusion Soft Polyester. Please see the KIP 800 Series Media Guide for details. |
Scanner / Copier | |
Resolution | 600 dpi (optical) |
Original | Single Sheet, image viewable / face up |
Widths | 210 mm – 914 mm (international standard page sizes to include ANSI, ARCH, ISO A & B, CHN, JPN) |
Length | 210 mm – 6 m |
Please see the KIP 2300 Scanner documentation for details on this optional scanner for the KIP 890 Colour System | |
Controller | |
Controller Type | System K Embedded, Windows Standard Embedded 7 – 64 bit, i5 Quad Cord (min) |
Memory | 4 GB (min) |
Compatible File Formats | Raster Colour: TIFF, JPG, JPG2000, PNG, BMP, GIF, TGA, RLE/RLC Vector Colour/B&W: HPGL, HPGL/2, HP-RTL, Postscript (PS/EPS), Adobe PDF, Autodesk DWF, Multipage PDF & DWF Raster B&W: TIFF Group 3 & 4, CALS Group 4, Grayscale TIFF Vector B&W: Calcomp 906/907 |
Space, Electrical & Environmental Requirements | |
Total Space (minimum) | 4500 x 2600 mm (W x D) (KIP 880 with KIP 720) 4500 x 5190 mm (W x D) (KIP 880 with KIP 720 with optional rear print stacker) The flexibility of the KIP 880-890 system permits the scanner to be placed perpendicular or parallel to the KIP printer for individual workflows, which can result in special requirements that may differ than noted above. System access through standard door frames without lifting or tilting. |
Electrical Requirements | EU/UK: Two – 20-240 V, 50/60 Hz, 16 A (one for KIP Printer and one for KIP Scanner) |
Electrical Receptacle | Europe = CEE 7 (x2) UK = BS 546 (x2) All other regions = please refer to your local standards |
Network Port | RJ-45 port-CAT5 or higher. LAN rated at least at 100 MB. Recommended is 1000 MB |
Room Temperature | 10 – 30°C |
Humidity | 15 – 80% RH |
Site Survey | KIP 800 Colour Series site survey documentation is to be completed prior to system installation |
Delivery
We aim to have your order on your door step as soon as possible and to achieve this we use a combination of shipping from our own inventory as well as using our suppliers who are able to deliver direct to our customers.
With warehouses located across the country, Global Office Machines is able to offer Australia-wide delivery.
Because we provide same day dispatches on all orders for in stock items placed before 2pm, delivery to all metro areas nationwide are usually delivered on the following business day, however, allow up to 3 business days.
For all regional locations across Australia, delivery times vary between 2-7 business days.
These delivery times do not take into consideration any issues beyond our control e.g. courier problems or out of stock products. Any orders that contain backordered products will have the items in stock shipped as per usual and the back order items will be sent as soon as they are in stock. You will be notified if part of your order is not currently in stock.
Delivery costs are charged based on the weight and dimensions of your order as well as the delivery location.
Any deliveries of photocopiers, wide format printers or large multifunction machines will require a forklift on site as these items weigh anywhere between 45kg and 300kg.
If your order is affected by specialised delivery rules such as the requirement of a forklift or tail lift due to weight restrictions, our service team will contact you in order to provide a manual quotation for your review.
Printers that can be delivered by courier in Sydney Metro with no extra equipment required are charged at a $25 flat rate.
Delivery on all toners, inks and wide format inks will incur a flat rate charge of $9.90 in Sydney Metro areas (assuming no promotions are running).
Delivery on all wide format paper will incur a flat rate charge of $17.95 in Sydney Metro areas, however, bulk orders of 5 or more boxes may incur further costs.
Signature on delivery is required for all orders as a proof of delivery and due to this we do not deliver to PO Box addresses.
As previously mentioned, shipping times vary depending on stock availability, delivery location and couriers. No pickups available in any state.
Delivery addresses must be available throughout standard business hours (anywhere from 8am – 5pm) between Monday to Friday. Couriers cannot call on approach when items are being delivered so if no one is onsite to accept the order, re-delivery must be organised. Note: extra charges may apply for re-delivery.
As per the delivery calculation tab, delivery on items that require either a forklift or tail lift will need to be quoted separately by our service team.
Global Office Machines do not accept returns under any circumstances unless the item you receive is damaged or faulty. If you receive your order and it is damaged upon arrival, DO NOT sign and accept the delivery.
In some cases, if a damaged package has been accepted we may be able to arrange for a return, however, you MUST contact our service team within 8 hours of receiving the damaged parcel.
For any return enquiries, contact the team at Global Office Machines on 1300 882 852 or email [email protected].
1 review for KIP 880 Multi-Touch Production Color Print System
Only logged in customers who have purchased this product may leave a review.
Hilary G. Montes –
In my workplace the printer is like the air conditioner. It’s the only one that isn’t turned off.
We’ve had other printers in the past but our KIP 880 multitasks superbly. It copies, scans and prints. I guess this is what is written in the brochure as its integrated dual footprint configurations. It saves us, in our office, precious time. We get to focus on the more important things other than minding the minutes; because we still need to make copies of scanned images, or have something else printed after that.
When it comes to printing, speed is as fast as 268 meters per hour. This reliability is complimented by its 4 medial roll switching, saving downtime once again and providing extended print runs. The inclusion of large capacity toner cartridges, for me is totally genius, as this also supports workflow efficiency. We’ve had other printers in the past that though you can put as many rolls that you can possibly put in it, it has a small toner cartridge. It wasn’t enough. Gosh, it was so sad using it. It’s like babysitting. You can’t do anything much.
Likewise, programming workflow automation in KIP 880 is quickly done in a single touch control on its smart system k 12” touchscreen.
To top it all off, for me the most important thing is, KIP 880 produces print quality; from the first to the final print. Technical drawing and graphics are with amazing colours. Images are robust and waterproof. It uses KIP 720 CIS scanner which is for a CAD oriented scanning. The 4 roll multi-function system is also with an integrated scanner.
Kip 880 also has optional integrated stacking folders or rear stacking systems, or KIPFold.
It is really fantastic to have a machine like this in our workplace.
